8-Port Gigabit Managed Reverse PoE Switch

• 7 PoE input and 1 PoE output 10/100/1000 Mbps RJ45 Ports
• 1 DC output port that supports both 5V and 12 V voltage switching
• Durable metal casing of superior quality and professional appearance
• Intelligent management via a web user interface and downloadable utility
• Green technology reduces power consumption

Description

Specification

• Rackmountable: No
• Managed: Yes
• Number of Ports: 8
• Max RJ45 Transfer Rate: 10/100/1000 Mbps
• Interface(s): 7 Passive PoE-in RJ45 Ports:
  10/100/1000Mbps Auto-Negotiation
  Voltage: 24/48 V (mixture is not supported)
  Power pin of Ethernet cable: 4/5+ 7/8-

  1 Passive PoE-out RJ45 Port:
  10/100/1000Mbps Auto-Negotiation
  Voltage: depending on the input voltage of PoE-in ports
  Power pin of Ethernet cable: 4/5+ 7/8-

  1 DC Output Port:
  Voltage: 5/12 V
• PoE Ports (RJ45): See above
• Standards and Protocols: "CSMA/CD

  IEEE802.3ab, IEEE802.3i, IEEE802.3p
  IEEE802.3q, IEEE802.3x, IEEE802.3u"
• Switching Capacity: 16 Gbps
• LED: "Power, Link/Act LED"
• Dimensions: 158 x 99.1 x 25 mm
• Transfer Method: Store-And-Forward
• Mac Address Table: 4 K
• Packet Forwarding Rate: 11.9 Mbps
• Jumbo Frame: 16 KB
• Additional Features: See Overview
• Quality of Service: Support Port-based/802.1p/DSCP priority
  Support 4 priority queues
  Rate Limit
  Storm Control
• Layer Features: L2:
  IGMP Snooping V1/V2/V3
  Static Link Aggregation
  Port Mirroring
  Cable Diagnostics
  Loop Prevention
• VLAN: Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
  MTU/Port/Tag VLAN
• Management: Intelligent management via a web user interface and downloadable utility
• Environment: Operating Temperature: 0°C~40°C (32°F~104°F)
  Storage Temperature: -40°C~70°C (-40°F~158°F)
  Operating Humidity: 10%~90% non-condensing
  Storage Humidity: 5%~90% non-condensing
• Package Contents: TL-RP108GE
  Power Cord
  Installation Guide
  Rubber Feet
• Package Type: Retail
• Package Weight: 0.4300 kg
• Warranty: 2 Years
• #Hide#POE: Yes
