The ROG Strix X670E-F Gaming WiFi is the stealthy alter ego of the Strix X670E-A. A substantial power buff relays its inner demon, giving exclusive ROG overclocking utilities even more headroom to unleash the potential of AMD Ryzen™ 7000 Series processors.

Black PCB and dark metallic heatsinks aesthetically match a wider variety of system hardware and build themes, while a dash of customizable color on its shroud subtly announces an ROG presence in your AM5 build.

• Power Stages - 16 + 2 teamed power solution rated for 90A per stage
• Overclocking Technologies - Dynamic clocking to simultaneously maximize Ryzen gaming and compute performance
• AI Cooling II - AI Cooling II uniquely balances noise and thermals for your system with a single click
• PCIe 5.0 - An x16 slot and two on-board M.2 slots are PCIe Gen 5-ready
• DDR5 - 6400 MT/s+, AMD EXPO, DRAM IC profiles, and AEMP
• DIY Friendly - Easy installation for GPUs and SSDs, plus simple BIOS resets and updates
• WiFi 6E - Faster-than-Gigabit WiFi that unlocks access to the low-interference 6 GHz band

Description

Specification

• Motherboard Type: Desktop
• Form Factor: ATX
• Socket: AMD AM5
• Chipset: AMD X670
• #Hide#DDR Type: DDR5
• CPU Support: Click here for CPU support
• RAM Technology: DDR5 (Dual Channel)
• RAM Slots: 4 x DIMM
• RAM Speeds: 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 MHz
• Maximum Memory: 192GB
• Graphics: Integrated Graphics*

  *Graphics specifications may vary between CPU types
• Graphics Ports: 1 x HDMI
  1 x DisplayPort
• PCI/PCI Express: 1 x PCIe 5.0 x16 (supports x16 mode)
  1 x PCIe 4.0 x16 (supports x4 mode)
  1 x PCIe 3.0 x1
• Storage: 4 x SATA III
  1 x M.2 (2242/2260/2280) - PCIe
  1 x M.2 (2242/2260/2280) - PCIe
  1 x M.2 (2242/2260/2280/22110) - PCIe
  1 x M.2 (2242/2260/2280) - PCIe
• RAID: AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10
• Wireless: Wi-Fi 6E
  2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
  Supports 2.4/5/6GHz frequency band
  Bluetooth v5.2
• LAN: 2.5GB LAN
• Audio: ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

• USB Ports Supported: 1 x USB 3.2 Gen2x2 Type-C (at back)
  2 x USB 3.2 Gen2 Type-C (at back)
  7 x USB 3.2 Gen2 Type-A (at back)
  2 x USB 3.2 Gen1 (at mid-board)
  6 x USB 2.0 (at mid-board)
  1 x Front USB 3.2 Gen2x2 Type-C connector
• Back Panel I/O Ports: "1 x USB 3.2 Gen2x2 (Type-C)
  9 x USB 3.2 Gen2 (7 Type-A, 2 Type-C)
  2 x USB 2.0
  1 x DisplayPort
  1 x HDMI
  1 x Wi-Fi Module
  1 x Intel I225-V 2.5Gb Ethernet
  5 x Gold-plated audio jacks
  1 x Optical S/PDIF out
  1 x BIOS FlashBack  button
  1 x Clear CMOS button "
• Internal I/O Connectors: 1 x 4-pin CPU Fan
  1 x 4-pin CPU OPT Fan
  1 x 4-pin AIO Pump
  5 x 4-pin Chassis Fan
  1 x 24-pin Main
  2 x 8-pin +12V
  4 x M.2 (Key M)
  4 x SATA 6Gb/s
  1 x USB 3.2 Gen2x2 connector (Type-C)
  1 x USB 3.2 Gen1
  2 x USB 2.0
  3 x Addressable Gen2
• .: 1 x Aura RGB
  1 x CPU Over Voltage jumper
  1 x Front Panel Audio (AAFP)
  1 x 20-3 pin System Panel
  1 x Thermal Sensor
  1 x Thunderbolt
• Accessories: 2 x SATA 6Gb/s cables
  1 x Thermal pad for M.2
  1 x ASUS Wi-Fi moving antennas
  1 x Cable ties pack
  1 x M.2 Q-Latch package for M.2 backplate
  1 x M.2 Q-Latch package
  1 x ROG key chain
  1 x ROG Strix stickers
  1 x ROG Strix thank you card
  2 x Rubber Packages for M.2
  1 x Rubber Package for M.2 backplate
  1 x User guide
• Additional Features: See Overview
• Package Type: Retail
• Package Weight: 2.6000 kg
• Warranty: 3 Years
• #Hide#M.2 Slot(s): Yes (M.2)
• #Hide#No. LAN Ports: 1 x LAN
• #Hide#Max LAN Speed: 2.5GB LAN
• #Hide#Wi-Fi: Yes (Wi-Fi)
• #Hide#RGB Lighting: Out of the box RGB lighting
